As power systems evolve to meet the growing demands of electrification, renewable integration, and digital control, transformer components must also adapt. At the center of this transformation lies a component that is often overlooked: the transformer bushing. More than a mechanical connection, the transformer bushing serves as a critical barrier between energized conductors and grounded transformer tanks. With the rise of smart grids, compact substations, and extreme environmental requirements, transformer bushings are now benefiting from a wave of material, design, and monitoring innovations. At NJREC, we’re at the forefront of these changes, delivering next-generation bushing solutions for everything from high voltage transformer bushings to compact wall bushing applications.
Historically, transformer bushings have been made using oil-impregnated paper insulation inside porcelain housings. While effective, this combination has drawbacks: it’s heavy, flammable, and vulnerable to oil leaks or aging-related dielectric breakdown. New materials now offer superior performance across multiple criteria.
RIS bushings replace traditional cellulose insulation with synthetic fiber mats impregnated with epoxy resin.
The result is a completely dry, oil-free bushing with improved partial discharge resistance and lower aging rates.
RIS bushings are lighter, environmentally safer, and more reliable in both indoor and outdoor installations.
Designed for integration with GIS (Gas Insulated Switchgear) systems, GIBs use SF₆ or environmentally friendlier gases under pressure to insulate the conductor.
They are ideal for compact substation designs, offshore wind platforms, or underground vaults.
Traditional porcelain is being replaced in many applications by epoxy-glass or silicone rubber composite materials.
These materials are resistant to cracking, UV degradation, and seismic stress, making them ideal for remote or harsh installations.
NJREC continues to expand its portfolio with new material innovations, offering both standard and custom-engineered solutions that match the latest performance and safety expectations.
As the power industry embraces digital transformation, real-time monitoring of critical assets is becoming the norm. Transformer bushings, once passive components, are now being fitted with smart sensors that actively report on their condition.
Partial Discharge Detection: High-frequency sensors detect internal dielectric stress before it causes failure.
Temperature and Load Monitoring: Sensors track bushing temperature fluctuations, which could signal hot spots, overloading, or external stress.
Moisture and Pressure Sensors: Especially for oil-filled or pressurized bushings, these sensors detect fluid loss or seal degradation.
These innovations allow asset managers to avoid unplanned outages, reduce manual inspections, and schedule proactive maintenance. NJREC’s transformer bushings can be equipped with integrated or retrofit sensor ports, making them fully compatible with digital substation environments.
As power infrastructure modernizes, a “future-ready” transformer bushing must do more than meet today’s voltage and mechanical standards—it must adapt to new system requirements.
Modern substations increasingly use Gas-Insulated Switchgear (GIS) and compact transformers to save space and reduce maintenance.
NJREC provides bushings compatible with GIS enclosures, enabling tight configurations without compromising insulation or safety.
New bushing designs are optimized to work with SF₆-free gas mixtures, reducing environmental impact while maintaining dielectric strength.
NJREC is actively developing bushings suited for systems that use dry air, Novec™ fluids, or fluoronitrile-based gases under pressure.
“Plug-and-play” modular bushings allow for faster installation and compatibility across various standards—ANSI, DIN, and EN—streamlining procurement and reducing downtime during retrofits.
Being future-ready also means accommodating growing system voltages and increased environmental stress, whether it’s higher pollution classes, altitude correction, or seismic resilience.
Innovation isn’t only about new materials—it’s also about how products are delivered and adapted to customer needs. At NJREC, we’ve optimized our custom engineering and production workflows to offer:
Shorter Delivery Times: Thanks to modular mold systems and an agile supply chain, we deliver custom bushings up to 20% faster than the industry average.
Tailored Creepage and Voltage Ratings: We adjust internal grading structures and external housing lengths based on your installation’s voltage class (1 kV to 52 kV), pollution level, and required creepage distance.
Installation Compatibility: Whether your application involves vertical, horizontal, or wall-mounted installation, we tailor the flange, mounting plate, and insulation geometry accordingly.
Our engineers collaborate closely with clients to evaluate their electrical, mechanical, and environmental specifications, ensuring every transformer bushing aligns with operational goals and compliance requirements.
Innovations in transformer bushing design benefit a wide variety of installations, from grid-scale substations to industrial switchgear and distributed renewables.
New insulation materials and monitoring technology increase uptime for high voltage transformer bushings used in transmission and generation.
In medium voltage grids, compact dry bushings allow for space-efficient switchgear and safer operation in urban or indoor locations.
Epoxy and composite bushings reduce weight and improve shock resistance for pad-mounted or enclosed switchgear systems.
Integrated sensors add diagnostic capacity to sealed systems where visual inspection is difficult.
Wall bushing applications benefit from slimmer designs, custom flanges, and pollution-resistant coatings—ideal for substations in industrial zones or extreme climates.
NJREC provides both standard and custom solutions for wall bushings, offering enhanced sealing and modular bolt patterns.
From offshore platforms to desert substations, today’s innovations help ensure transformer bushings operate with greater efficiency, safety, and longevity across environments and industries.
As power systems shift toward smarter, denser, and more sustainable infrastructures, transformer components must follow. The transformer bushing is no exception. With the latest advances in insulation materials, condition monitoring, compact designs, and environmental compatibility, today’s bushings are smarter, safer, and better equipped for tomorrow’s grid. NJREC is proud to be a trusted supplier of these next-generation solutions, supporting critical infrastructure with reliable, certified, and future-ready products. Contact us today to explore innovative transformer bushing options tailored to your next project.
