In today’s rapidly evolving electrical infrastructure, safety, reliability, and compactness are more critical than ever. One of the essential components supporting these goals in power distribution systems is the bushing—a device that allows electrical conductors to safely pass through grounded enclosures such as transformer tanks or switchgear walls.
Traditionally, bushings were made from porcelain or oil-impregnated paper insulation. However, as grid demands become more complex and environments more challenging, epoxy resin bushings have emerged as the preferred alternative due to their excellent electrical insulation, mechanical strength, resistance to environmental conditions, and ability to be molded into complex, compact shapes.
Epoxy resin bushings are widely used in low- and medium-voltage distribution transformers, which are the workhorses of local electrical grids. These transformers are commonly deployed in:
Residential neighborhoods
Commercial complexes
Industrial zones
Rural electrification systems
Distribution transformers typically operate in the 11 kV to 33 kV range and require bushings that can handle high dielectric stress while maintaining a small footprint. Epoxy resin bushings provide an ideal insulation solution, ensuring a safe connection between the internal transformer windings and external power lines.
Unlike oil-impregnated bushings, epoxy bushings offer dry insulation, meaning no risk of oil leakage or fire hazards, and minimal maintenance. This makes them particularly valuable for pole-mounted or pad-mounted transformer installations where service access may be limited.
The moldability of epoxy resin allows for highly customized designs, including:
Integrated creepage sheds for pollution control
Compact cross-sectional shapes for space-constrained applications
Pre-molded flanges and terminal fittings for quick installation
By reducing size and improving integration, epoxy resin bushings help transformer manufacturers deliver smaller, more efficient, and safer products—key advantages in urban or indoor installations where space is at a premium.
Switchgear cabinets and Ring Main Units (RMUs) play a vital role in modern medium-voltage power distribution, enabling isolation, protection, and rerouting of electrical loads. These systems are commonly used in:
Secondary substations
Wind and solar power control stations
Building-level distribution panels
Underground vault installations
Due to the compact and often sealed nature of switchgear and RMUs, the components inside must be both space-efficient and highly reliable. Epoxy resin bushings are ideal for such applications, offering:
Integrated design for space-saving layouts
Non-hygroscopic properties that prevent moisture ingress
High tracking and erosion resistance for polluted environments
One of the major challenges in switchgear systems is the risk of internal arc faults, which can lead to thermal damage or even explosions. Epoxy resin bushings offer enhanced arc resistance and do not shatter like porcelain, reducing the risk of equipment failure and injury.
Additionally, epoxy bushings used in outdoor switchgear are often UV-resistant and can operate in extreme temperatures, from -40°C to +120°C, ensuring long-term performance in exposed or remote locations.
In compact RMUs, epoxy bushings often form an integral part of the cast-resin insulation system, allowing for better space utilization and simplified assembly, supporting the advancement of smart and modular power infrastructure.
Another critical application of epoxy resin bushings is in cable terminations and feedthroughs, where they serve as interfaces between power equipment (such as transformers or switchgear) and underground or armored cables.
These cable interfaces are especially common in:
Urban underground networks
Industrial automation systems
Tunnel and metro power supplies
Offshore or marine environments
In these applications, the bushing must provide:
Mechanical support to the heavy cable
Electrical insulation to prevent flashover
Environmental sealing to keep out moisture, dust, or chemicals
Epoxy bushings perform all of these roles excellently. Their solid, seamless construction avoids any internal gaps or interfaces that could lead to partial discharges or tracking. Moreover, epoxy's chemical resistance makes it suitable for aggressive environments, including those with salt spray, industrial gases, or oil vapors.
Cables, particularly medium- and high-voltage ones, can exert significant mechanical loads on their connection points. Epoxy resin bushings provide the mechanical durability needed to withstand:
Cable tension and bending forces
Thermal expansion/contraction cycles
Vibration from switching or external impacts
Epoxy bushings also possess excellent moisture resistance, critical in cable trench or underground vault applications where humidity and condensation are persistent threats.
By offering a stable, maintenance-free connection between cables and electrical equipment, epoxy bushings help enhance the overall reliability and safety of underground distribution networks.
As the demand for Electric Vehicle (EV) infrastructure surges, so does the need for safe and reliable medium-voltage connections in fast-charging stations. These charging units require bushings that can handle high current loads in compact environments, often exposed to variable weather conditions.
Epoxy resin bushings are the ideal solution for:
High-voltage busbar feedthroughs
Transformer terminations in charging units
Control cabinet insulation interfaces
Their thermal and electrical endurance ensures continuous operation even during peak usage periods, making them a core component of the future-ready EV ecosystem.
In solar farms, inverter stations convert DC energy from panels into usable AC energy, typically at medium voltage. The output of these inverters must be safely routed through switchgear or step-up transformers—applications that rely heavily on bushings.
Epoxy resin bushings used here offer:
Compact design for containerized inverter stations
Resistance to UV radiation and thermal cycling
Dry insulation that avoids the need for oil or gas-based systems
Their ability to perform in remote, high-temperature, or sandy conditions (common in solar installations) further underscores their relevance in renewable applications.
Additionally, the combination of low maintenance requirements and long service life supports the renewable sector’s focus on sustainability and cost-efficiency.
From traditional distribution transformers to cutting-edge smart grids and EV infrastructure, epoxy resin bushings play a central role in ensuring safe, reliable, and efficient power delivery. Their unmatched advantages—compact size, mechanical toughness, electrical insulation, and environmental resistance—make them a preferred component across a wide spectrum of power distribution systems.
As energy systems continue to modernize, the demand for versatile, durable, and maintenance-free components will only increase. Epoxy resin bushings are well-positioned to meet these challenges and contribute to a smarter, greener electrical future.
If you're seeking high-quality epoxy resin bushings tailored for demanding applications, look no further than Nanjing Rainbow Electric Co., Ltd. With advanced manufacturing capabilities and a commitment to product reliability, they are a trusted supplier of cast resin insulation components for global power systems.
