As modern power systems grow in complexity, reliability, and energy efficiency requirements, the performance of each transformer component becomes crucial. Bushings—essential parts that allow electrical conductors to pass through grounded barriers such as transformer tanks—play a vital role in maintaining the dielectric integrity of the system. With increasing voltage ratings, compact installations, and harsh environmental exposure, traditional materials like porcelain and oil-impregnated paper often fall short.
Today’s grid demands components that are more compact, robust, environmentally friendly, and maintenance-free. This shift has accelerated the adoption of epoxy resin insulation systems, especially in bushings for medium- and high-voltage transformers.
Epoxy resin is a thermosetting polymer that offers high dielectric strength, excellent thermal stability, chemical resistance, and strong mechanical properties. These characteristics make it particularly suitable for cast insulation systems in electrical equipment, including transformer bushings.
Unlike oil-paper or ceramic bushings, epoxy resin bushings are molded as solid units, eliminating the need for oil and the associated maintenance. Their non-hygroscopic, arc-resistant, and pollution-resistant nature has redefined performance standards in power distribution.
Transformer bushings serve as critical pathways for electrical current to flow safely from the internal windings of the transformer to the external power grid or load systems. This connection must occur through the grounded transformer tank or enclosure, without compromising electrical insulation or safety.
A typical bushing contains a central conductor, usually made of copper or aluminum, which carries the high voltage. Surrounding this conductor is an insulating material—in this case, epoxy resin—that provides the necessary dielectric strength to prevent electrical breakdown.
Epoxy resin bushings are designed as solid, one-piece structures where the resin is cast around the conductor using precision molds. This technique eliminates voids and moisture pockets, both of which can cause partial discharge or insulation failure.
The bushing’s external surface is shaped with creepage sheds or ribs that increase the surface distance along which leakage current would have to travel. This helps in enhancing surface insulation, especially in polluted or humid environments.
Bushings are typically installed at the top or side of the transformer enclosure, depending on the design. Their function extends beyond just mechanical support—they:
Electrically insulate the high-voltage conductor from the grounded tank
Physically support the conductor against mechanical stresses
Protect the internal components from environmental influences
In oil-immersed transformers, one portion of the bushing is submerged in oil, while the other is exposed to air. In dry-type systems, the bushing forms part of the overall solid insulation system.
Whether in medium-voltage distribution transformers or high-voltage power transformers, bushings are essential for ensuring safe, efficient energy transfer between internal and external electrical networks.
One of the standout features of epoxy resin is its superior moldability. Unlike ceramic or porcelain, epoxy resin can be cast into complex geometries using high-precision tooling. This allows for:
Smaller overall dimensions
Integration of features like mounting flanges, creepage sheds, or bushings with customized contours
Lightweight designs for easier transport and installation
In compact or modular transformers—common in urban infrastructure or renewable energy installations—space optimization is critical. Epoxy resin bushings enable the design of smaller, more efficient systems without sacrificing performance.
Mechanical durability is another compelling reason to use epoxy resin in transformer bushings. Epoxy resin exhibits:
High compressive and tensile strength
Resistance to mechanical vibrations and impacts
Fracture tolerance in extreme environments
Porcelain bushings, although historically common, are brittle and susceptible to cracking or catastrophic failure from external shock or mishandling. Epoxy bushings, in contrast, can withstand impact loads and temperature-induced stress without structural compromise.
This makes them ideal for seismically active regions, mobile transformer units, or outdoor substations where environmental conditions can be harsh and unpredictable.
Epoxy resin’s electrical insulation properties are exceptional. Its high dielectric strength ensures that even at elevated voltages, no breakdown or flashover occurs between the conductor and the grounded transformer tank.
Additionally, epoxy resin maintains excellent performance across a wide temperature range:
Suitable for environments from -40°C to +120°C
Stable dielectric behavior under thermal cycling
Low dielectric loss, reducing heat generation
The material also resists tracking, corona discharge, and partial discharge—phenomena that can degrade insulation over time.
Together, these features ensure that epoxy resin bushings maintain long-term reliability in both high-voltage and high-temperature applications, outperforming many legacy insulation technologies.
Epoxy resin bushings are versatile and used extensively in both oil-immersed and dry-type transformer applications:
In oil-immersed transformers, epoxy resin bushings are used at the tank interface to provide a sealed, insulated path for high-voltage conductors. Some epoxy bushings are designed with oil-resistant seals and metal end flanges to ensure leak-free integration.
Advantages include:
Improved insulation interface between oil and air
Better resistance to thermal aging compared to oil-paper insulation
Compact designs that reduce tank size
In dry-type transformers, which do not use oil or other liquid coolants, epoxy resin is often the main insulation material. Bushings in such systems need to be dry, solid, and robust—exactly what epoxy resin delivers.
Key benefits include:
Compatibility with cast resin transformer systems
Easy installation without handling of fluids
Safer and more environmentally friendly
Epoxy bushings in dry-type transformers also help achieve low partial discharge levels, which is critical for indoor installations or sensitive industrial applications.
Urban areas present a challenging operating environment for transformers. These challenges include:
Space limitations
Polluted atmospheres with dust, moisture, and industrial chemicals
High and fluctuating loads
Epoxy resin bushings perform exceptionally well under these conditions. Their compact size makes them suitable for pad-mounted or vault-type transformers in constrained spaces. The non-hygroscopic and pollution-resistant surface of epoxy reduces surface leakage currents, helping avoid flashover in polluted or humid settings.
In high-load distribution networks where transformer failure can lead to blackouts, downtime, or financial loss, epoxy bushings are a proven solution offering superior performance with minimal maintenance.
They are now standard in:
Metro power substations
Renewable energy interfaces (wind and solar step-up transformers)
Smart grid-ready transformer stations
Data center power distribution units
Epoxy resin’s inherent arc and flame resistance minimizes the risk of fire or explosion in case of internal fault or external flashover. Some formulations are UL94 V-0 certified, indicating they self-extinguish in the presence of fire.
Additionally, many designs incorporate arc-deflecting geometries, directing fault energy away from personnel or adjacent equipment.
Traditional porcelain bushings are subject to failure due to cracking, pollution flashover, or oil leakage. Epoxy bushings eliminate these weak points with:
Seamless cast construction
Pollution-resistant surfaces
No oil content (dry-type)
High resistance to UV and weathering
As a result, users experience fewer unplanned outages and lower lifecycle costs. In remote or hard-to-access substations, this can translate into substantial savings and enhanced reliability.
Epoxy resin bushings are eco-friendly alternatives to oil-based systems. They contain no toxic or flammable fluids and are easily recyclable at the end of life.
Many epoxy bushings maintain performance for 20–30 years, even under continuous electrical and mechanical stress. Their long lifespan and minimal service needs support sustainability and reduce the total environmental footprint of power infrastructure.
In today’s demanding power systems, epoxy resin bushings have become a vital upgrade for enhancing transformer performance. With superior electrical insulation, mechanical strength, and environmental resistance, they ensure safer, more efficient, and low-maintenance operation—ideal for urban substations, renewable energy setups, and oil-immersed transformers alike.
